Description

Part No: BV260S – Recirculating Desktop Spray Booth

The BenchVent BV260S recirculating spray booth is bigger than the BV300S and with its 2 external rotor axial fans and it’s as powerful as the more expensive BV200S. It can take up to B3 size artwork, which is between an A3 and an A2 size 3.

The BV260S is portable and an ideal air filtration solution for hobby work shops, design and technology classrooms, as well as airbrushing demos in shops or during exhibitions and shows.

This is a recirculating unit and doesn’t require an external vent. Instead, it is fitted with carbon impregnated fibre filter which makes it suitable for use with solvent fumes.

The BV260S is not recommended for continued use, such as in production applications, especially in extremely confined areas where harmful solvent vapours and fumes may accumulate. For this environment, you will need higher specification extraction cabinets such as BV660H-C or BV930H-C.

Like all BenchVent units, the BV260S comes with lifetime warranty.

Download the datasheet for more information: BV260S Datasheet

Uses include filtration of:

Solvent fumes and mist from aerosol adhesives, aerosol lacquers, fixatives, resins, solder fumes, dusts and airbrush spray paints.

Recommended applications:

• Craft
• Hobby
• Scale model painting
• Airbrush painting
• Light grinding particles and dusts
• Cleaning solvents

BV260S recirculating spray booth description:

• Body: Black powder coated steel case with white back stand and black carry handle
• Filters: Particulate + Carbon Impregnated Fibre Filter
• Motor: 2x external rotor motor axial fans, brushless, UL, VDE and CSA approved
• Others: Sealed electrical wiring and switch, downstream of filters

Operation:

Place the unit on a desk, bench or trolley, attach the shield, plug in and switch on.

The BenchVent BV260S re-circulating spray booth can be used in two positions:

• Reclining (on back stand) – ideal for spray mounting artwork or applying lacquers or fixatives.
• Upright: For airbrushing models, light grinding particles, sanding and general solvent dilution.

This unit is designed predominantly for studio, D&T classrooms, workshop cleanliness and for immediate operator protection against concentrations of airborne contaminants. They are not recommended for continuous usage such as production applications, particularly in confined and/or badly ventilated areas. (See extraction cabinets BV300S-D, BV200H & BV100H-D for complete vapour extraction for higher specification filtration.)

Demonstrating adequate control of risks to the health of employees, students and the general public from dusts, powders, mists, fumes, and vapours is the fundamental requirement of the Control of Substances Hazardous to Health (CoSHH) regulations 2002 and 2004.

Additional information

Weight	23 kg
Dimensions	615x490x495mm (WxDxH) 10kg Weight
Description	Steel construction finished in black –– plastic replaceable spray/fume shield – back stand / carry handle – particulate filter – carbon impregnated fibre filter – axial fan, external rotor motor type brushless, UL, VDE and CSA approved – sealed electrical wiring and switch, downstream of filters.
Air Volume at Free Air	610 m3/hr
Ave. Air Velocity at filter face	0.60 m/sec
Ave. Air Velocity at Hood Face	0.35 m/sec
Fan Motor Spec	230 V 50Hz 90W, 115V 60Hz 84W
Noise Level dB(A)	61 db(A)
